Subwoofers
Neumann KH 810 G
34 450,00 kr
📦 Beställningsvara
🚚 Leveranstid: Kontakta oss
Subwoofer av rang.
Leveranstid: Kontakta oss
• Free field frequency response ±6 dB: 17 … 600 Hz
• Free field frequency response ±3 dB: 18 … 300 Hz
• Reproduction accuracy between 50 Hz and 100 Hz: 100%, 80%, 50% of subwoofers produced: ±1.20; ±0.54; ±0.28 dB
• Self-generated noise at 10 cm (with input gain set to 100 dB SPL for 0 dBu): <20 dB(A) SPL
• Sine wave output with a THD < 0.5 % at 1 m in half space: 95 dB SPL (>45 Hz)
• Bass capability: Max. SPL in half space at 3% THD at 1m (averaged between 50 Hz and 100 Hz): 110.7 dB SPL
• Max. long term SPL with pink noise at 2.3 m, in typical listening conditions (single / pair full range): 112 dB SPL
• Analog input(s): 8 x XLR: analog electronically balanced
• Analog input impedance: >13k Ohms
• Max. input level: +19 dBu
• Common mode rejection ratio (CMRR): > 56 dB @ 15 kHz
• Crosstalk (1 kHz), level matching: -95 dB; ±0.1 dB
• Volume control: NRC 1 hardware remote or RS-232
• Volume control range; resolution: 118 dB; 0.25 dB
• Analog dynamic range; THD+N: 119 dB(A); <0.001% (-100 dB)
• Signal routing modes: LFE 80+re-routing; LFE 80 Hz; LFE 120 Hz; Wide
• LFE Gain: 0 / +10 dB
• Analog output(s): 8 x XLR; analog electronically balanced
• Input gain control (sensitivity): +2 ... -12 dB
• Output level control (output level in 1 m based on 0 dBu input level): 100; 114 dB SPL
• Controller design: Analog, active
• Crossover frequency: 80 Hz
• Crossover slope: 24 dB/oct; 4th order
• Equalization: Low cut: 30 Hz; 0 … -12 dB
• Equalization: Parametric EQ: Gain: +4 ... -12 dB
• Equalization: Parametric EQ: Frequency: Bypass; 20 ... 120 Hz
• Equalization: Parametric EQ: Q: 1 ... 8
• Phase: 0; 45; 90; 135 and 0/180 deg
• Protection circuitry: Peak and thermo limiters
• Infrasonic filter: frequency; slope: 6.5 Hz; 12 dB/oct.
• Remote control: RJ45 connector: Via NRC1 remote control (optional): volume for all channels; bass management on/off; LFE gain 0/10 dB.Via RS-232: more parameters remote controllable
• Display: On; Normal Operation: Red LED
• Display: Limit / Clip / Errors / Protection /Boot Mute / Shut Down Mute: Red LED
• Display: Bass Management on: Green LED
• Output power woofer amplifier (THD+N with limiter deactivated: 10%): 200 W
• Output power woofer amplifier (THD+N with limiter deactivated: 0.1%): 160 W
• Mains Power Supply: input voltage; frequency: 220-240 / 100-120 V (switchable); 50/60 Hz
• Power consumption (230 V / 100 V): Idle: 20 W
• Power consumption (230 V / 100 V): Full output: 290 W
• Cabinet material: Wood cabinet, aluminum electronics panel
• Cabinet surface finish; color (front / back): Painted; metallic anthracite (RAL 7021) / black (RAL 9005)
• Operating conditions: +10° C to +40° C (+50° F to +104° F); <90% RH, non-condensing
• Transport/storage conditions: -25° C to +70° C (-13° F to 158° F); <90% RH; non-condensing
• Woofer: 265 mm (10") with magnetic shielding and protecting black metal grille
• Product dimensions (height x width x depth): 360 x 330 x 645 mm (14.2" x 13" x 25.4")
• External net volume: 76.6 liters
• Product weight: 26 kg (57 lbs 5 oz)
• Cabinet weight when electronics remote located: 24.2 kg (53 lbs 6 oz)
• Packed dimensions (height x width x depth), mm (inches): 515 x 490 x 750 mm (20 1/4" x 19 1/4" x 29 1/2")
• Packed weight: 32.0 kg (70 lbs 9 oz)
• Packed cube: 0.189 m³
| Tum | 10 |
|---|---|
| Färg | Svart |
| Watt | 200 |
| Produkttyp | Subwoofers |
| Högtalare | 1 |
| Märke | Neumann |
